SALE -Golden Harvest V3 Boards- 50 fonts

Description

Technical specifications

➢ tiny dimensions of 28.5 mm x 18.5 mm x 3.7 mm / 1.12 ” x 0.73 ” x 0.15 ”

➢ powered by 3.7 V (single 18650 Li-ion cell for example)

➢ provides 9 LED channels that can be customized independently from each other:

o 4 LED channels can deliver up to 9 A each:

▪ can drive SingleCrees, DualCrees, TriCrees and QuadCrees

▪ can drive Neopixel

o 4 LED channels can deliver up to 20 mA each:

▪ can drive accent, crystal chamber or switch LEDs for example

o capable of delivering up to 36 A in sum (in practice, both battery and heat dissipation

are the limiting factors here)

o full customizability even of accent LEDs such as switch LEDs or crystal chamber LEDs

using the whole range of our effect engine

➢ optional USB charging and file transfer feature (using our Seedling module, see below)

➢ microSD card slot

Installation and Use

➢ huge solder pads for easiest installation possible

➢ your hardware setup can be easily chosen per drag-and-drop on the microSD card

➢ full functionality accessible even if used with only one momentary switch

➢ can also be used with one momentary and one latching switch as well as with two

momentary switches

➢ customizable deep sleep (hibernation mode)

Audio Engine

➢ maximum audio amplifier power output: 4 W

o supported speaker power: 1 W – 6 W

o supported speaker impedance: 4 Ohm, 8 Ohm, 16 Ohm and 32 Ohm

o high dynamic range: 115 dB

o real-time dynamic range compression

o high signal-to-noise ratio: 100 dB

o 16 bit audio sample resolution

o integrated speaker protection algorithms:

▪ exceeding voice coil excursion protection

▪ overtemperature protection

▪ overcurrent protection

▪ undervoltage protection

▪ 15 kV ESD protection of speaker output

SD CARD FONTS



Current font package – 48 fonts

sound1 – Balance

sound2 – Psy-Borg

sound3 – Daddy Issues Complete

sound4 – Guardian

sound5 – Cryo Carbon

sound6 – Peace

sound7 – Violence

sound8 – Son of Darkness

sound9 – The Eternal Prince

sound10 – The Phantom

sound11 – The Shadow

sound12 – Shadows

sound13 – Dark Harvest

sound14 – The Classic Villain

sound15 – Energy Pike

sound16 – Knighthood

sound17 – KRossguard

sound18 – Final Steps

sound19 – Darksaber

sound20 – Ascension

sound21 – Crimson Menace

sound22 – Traveler

sound23 – Young Solo

sound24 – Empress

sound25 – Duke

sound26 – The Bold One

sound27 – Rogue Commander

sound28 – Darkness

sound29 – Graflex

sound30 – Fallen Order

sound31 – General

sound32 – Dark Revan

sound33 – Starkiller

sound34 – Defiance

sound35 – Rainbow

sound36 – Codex of Light

sound37 – Cyber Terror

sound38 – Dark Ages

sound39 – Hatred

sound40 – Idyll

sound41 – Serenity

sound42 – The Champion

sound43 – The Dark Lord Revisited

sound44 – The Learner

sound45 – The Second

sound46 – The Teacher

sound47 – Whispers of Power

sound48 – Darkwolf
